por
Catalytic silencer
1
1
1
2
2
3
4
5
5
6
7
8
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
screw
827192
Não disponível
2
Spring washer 8,5x5,1x1,5
016405
3,49€ Preço unitário com IVA
3
Plain washer 5,4x10x0,8
003055
3,53€ Preço unitário com IVA
4
Protection
482280
Não disponível
4
Guard
480990
Não disponível
5
Washer
013754
2,46€ Preço unitário com IVA
6
Nut
001564
2,77€ Preço unitário com IVA
7
Spring washer 13,75x8,15x4,5
016408
3,49€ Preço unitário com IVA
8
Washer
016604
2,77€ Preço unitário com IVA
10
Gasket
432127
Não disponível
11
screw M8x30
015792
3,07€ Preço unitário com IVA
12
Exhaust pipe
484344
Não disponível
13
Flanged nut
015341
3,56€ Preço unitário com IVA
14
Plain washer 12x5.2x1
006078
2,03€ Preço unitário com IVA
15
Screw m8x50
432334
Não disponível
15
Hex socket screw M8x50
844483
2,47€ Preço unitário com IVA
16
Guard
825327
Não disponível
17
Tyre
486993
Não disponível
18
Guard
486985
Não disponível
19
Muffler, assy.
827170
Não disponível
19
Muffler, assy.
478520
Não disponível
20
Tyre
825868
Não disponível
21
Washer ø10.2xø15x2
016195
5,71€ Preço unitário com IVA
22
Screw w/ flange M10
433122
6,59€ Preço unitário com IVA
23
Washer
827193
Não disponível
24
Washer
827564
Não disponível
24
Washer
103556
Não disponível

Encontre nesta página o esquema detalhado Catalytic silencer GILERA PIAGGIO VESPA. Esta vista explodida permite identificar os diferentes componentes de que necessita para a manutenção da sua máquina e encontrar rapidamente a respetiva referência da peça original GILERA PIAGGIO VESPA.


Os esquemas não são contratuais. Em caso de dúvida, os nossos profissionais estão disponíveis para responder às suas perguntas. Ao adicionar uma peça ao carrinho, certifique-se de encomendar a quantidade pretendida. O preço unitário indicado corresponde ao preço de cada referência para uma quantidade de 1.
